MT-TP50E

特点/Features:​

1. 底板设计适合低矮车间；

2. 采用周轴，板式低床和钢丝绳链条平衡系统，举升机升降平稳；

3. 液压动力单元配置可调节装置，始终可以调节下降速率；

4. 电锁释放，方便快捷；

5. 对称立柱设计允许更宽的通道通过；

6. 配有24V限位开关；

7. 橡胶垫支撑采用双螺旋式调节高度和分段式调节高度；

8. 橡胶垫门开启保护；

9. 脚部保护装置提供；

10. 经过115%动态和150%静态负荷测试；

11. CE认证。

​

1. Floor plate design is ideal choice for low ceiling shop.

2. By two cylinder, plate and wire rope chain balance system, lifting off and landing smooth.

3. Hydraulic power unit configuration throttling device, can always adjust the rate of decline.

4. Electric lock release, convenient and quick.

5. Symmetric column allows wider drive through clearance.

6. With 24V limit switch for optional.

7. Rubber support pad with spiral adjust the height and in stages adjust the height, optional. Truck adapters can be optional.

8. Rubber pad door-opening protection.

9. Toe protection device provided.

10. Have adopted 115% dynamic and 150% static loading tested.

11. CE Approved.
